ANALOG WAY - Aquilon C+
Mélangeur 4k/8k, chassis 5RU, jusqu'à 24 entrées 4k et 20 sorties 4k, 2 multiviewers
Technical properties
- Dimensions unitaires : 482 x 221 x 700 mm
- Poids unitaire : 37 kg
- Consommation électrique : 1010 W
Product details
- Industrial grade reliability
- Fully modular and scalable architecture
- FutureFuture-proof modular design with a full set of field swappable I/O cards : 8x HDMI 1.4, HDMI 2.0, DP 1.2, 12G 12G-SDI, 2.5GbE NDI+12G 12G-SDI,
- SFP+, Optical Fiber, SDVoE and more to come
- UltraUltra-low latency 10/12 12-bit 4:4:4 video processing
- Up to 120 Megapixels throughput on Program at 10 10-bit 4:4:4 @60Hz
- Up to 24x 4K60p or 48x 2K/DL inputs depending on installed input cards
- Up to 20x 4K60p outputs
- Up to 12x 4K or 24x 2K/DL mixing layers (+live backgrounds)
- High Frame Rate up to 144Hz
- RealReal-time 3D 3D-LUT based SDR/HDR10/HLG conversion and color correction
- Intuitive HTML5 HTML5-based user interface with live source thumbnails
- Native DANTE audio networking hardware and support
- Option to link to up to 3 other LivePremier systems
